10" Disc Brake Assemblies

Stainless Steel

BEARING 1-1/16" [44649] qty2 BEARING 1-3/8" [68149] qty2 SEAL 1-3/8"[UFP][257-168] qty2 BEARING PROTECTOR SET S/S #1.980 qty1 DISC ROTOR AND HUB S/S 10" 5L [UFP] qty2 DISC BRAKE CALIPER S/S LH [UFP DB35 qty1 DISC BRAKE CALIPER S/S RH [UFP DB35 qty1 7/16"X1"SHCS BOLT [UFP DISC CALIPER qty4 COTTER PIN 1/8"X1-1/4"[UFP AXLE] qty2

12" Disc Brake Assemblies

2 sizes available

BEARING 1-1/4" [67048] qty2 BEARING 1-3/4" [25580] qty2 SEAL 1-3/4"[UFP][21333] qty2 BEARING PROTECTOR SET #2.717 qty1 DISC ROTOR AND HUB S/S 12" 8L [UFP] qty2 DISC BRAKE CALIPER S/S LH [UFP DB35 qty1 DISC BRAKE CALIPER S/S RH [UFP DB35 qty1 7/16"X1"SHCS BOLT [UFP DISC CALIPER qty4 COTTER PIN 1/8"X1-1/4"[UFP AXLE] qty2

2" x 2" 93" Track 76"SC Straight Spring Axles

3 sizes available

2"x2" 93" Track 75"SC "V" Spring Axles

5 sizes available

2"x2" 93" Track 75"SC Straight Spring Axles

2 sizes available

2"x2" 93" Track 76" SC "V" Spring Axles

7 sizes available

2"x2" 93" Track 77"SC Straight Spring Axles

2 sizes available

2"x2" 71" Track 57-3/8"SC Straight Spring Axles

4 sizes available

2"x2" 81.5" Track 68-3/8" SC "V" Spring Axles

3 sizes available

2"x2" 84" Track 67" SC "V" Spring Axles

4 sizes available

2"x2" 84" Track 67" SC Straight Axles

2X2X84TR 67SC 5L HD W/BRK. FLANG

2"x2" 84" Track 68" SC "V" Spring Axles

2X2X84TR 68SC 5LHD

2"x2" 84" Track 68"SC Straight Spring Axles

2 sizes available

2"x2" 86.5" Track 77 3/8"SC Straight Spring Axles

3 sizes available

2"x2" 86.5"Track 73-3/8"SC "V" Spring Axles

4 sizes available

2"x2" 87" Track 73-3/8"SC "V" Spring Axles

2 sizes available

2"x2" 88" Track 73-3/8"SC Straight Spring Axles

2 sizes available

2"x2" 91"Track 73"SC "V" Spring Axles

4 sizes available

2"x2" 91"Track 73"SC Straight Axles

2 sizes available

2"x2" 93.5" Track 80-3/8"SC Straight Spring Axles

3 sizes available

2"x2" 93" Track 77.5" SC "V" Spring Axles

3 sizes available

2"x2" 93" Track 77.5"SC Straight Spring Axles

2X2X93TR 77.5 SC 5L HD

2"x2" 93" Track 78.5"SC "V" Spring Axles

3 sizes available

2"x2" 93"Track 77"SC "V" Spring Axles

3 sizes available

2"x2" 95" Track 78.5"SC "V" Spring Axles

2 sizes available

2"x3" 84" Track 67"SC "V" Spring Axles

3 sizes available

2"x3" 86.5" Track 73-3/8"SC "V" Spring Axles

2 sizes available

2"x3" 86" Track 67"SC "V" Spring Axles

3 sizes available

2"x3" 91" Track 73"SC "V" Spring Axles

4 sizes available

2"x3" 93.5" Track 80-3/8"SC "V" Spring Axles

2 sizes available

2"x3" 93" Track 75"SC "V" Spring Axles

6 sizes available

2"x3" 93" Track 75"SC Straight Spring Axles

2 sizes available

2"x3" 93" Track 76.5"SC "V" Spring Axles

2 sizes available

2"x3" 93" Track 76"SC "V" Spring Axles

6 sizes available

2"x3" 93" Track 78.5"SC "V" Spring Axles

2 sizes available

2"x3" 93" Track 80-3/8"SC Straight Spring Axles

2 sizes available

2"x3" 93" Track 86"SC Straight Spring Axles

3 sizes available

2"x3" 95" Track 76"SC "V" Spring Axles

2 sizes available

200-00061 ~ TORSION AXLE 2-1/2" "V" 88-3/4T 78FW 3.75K W/HUBS KNOTT (KARAVAN)

REPRESENTATION PHOTO MAGIC TILT TORSION AXLE W/ HUBS (KNOTT) TRACK (HUB FACE TO HUB FACE): 88-3/4" LUG NUTS NOT INCLUDED MOUNTING HARDWARE (NOT INCLUDED) ALUMINUM TUBE FRAME BOTTOM CHANNEL PY9145-T ALUMINUM I-BEAM FRAME PY9145 GALVANIZED TUBE FRAME U-BOLTS 95x12x10

200-00102 ~ TORSION AXLE 2-1/2" "V" 89-1/4T 74-1/2FW 3.75K W/HUBS KNOTT (KARAVAN)

REPRESENTATION PHOTO MAGIC TILT TORSION AXLE W/ HUBS (KNOTT) TRACK (HUB FACE TO HUB FACE): 89-1/4" LUG NUTS NOT INCLUDED MOUNTING HARDWARE (NOT INCLUDED) ALUMINUM TUBE FRAME BOTTOM CHANNEL PY9145-T ALUMINUM I-BEAM FRAME PY9145 GALVANIZED TUBE FRAME U-BOLTS 96x12x10

200-00124-GL ~ TORSION AXLE 2-1/4" STRAIGHT 53T 44FW 1.5K W/HUBS KNOTT (KARAVAN)

REPRESENTATION PHOTO MAGIC TILT TORSION AXLE W/ HUBS (KNOTT) TRACK (HUB FACE TO HUB FACE): 53" LUG NUTS NOT INCLUDED MOUNTING HARDWARE (NOT INCLUDED) ALUMINUM TUBE FRAME BOTTOM CHANNEL PY9145-T ALUMINUM I-BEAM FRAME PY9145 GALVANIZED TUBE FRAME U-BOLTS 60x13x8

3-1/2" x 3-1/2" 79"FW Straight Torsion Axles

3 sizes available

3-1/2" x 3-1/2" 79"FW "V" Torsion Axles

3 sizes available

3" x 3" 69"FW Straight Torsion Axles

2 sizes available

3" x 3" 70"FW "V" Torsion Axles

2 sizes available

3" x 3" 70"FW Straight Torsion Axles

2 sizes available

3" x 3" 76"FW "V" Torsion Axles

2 sizes available

3" x 3" 76"FW Straight Torsion Axles

2 sizes available

3" x 3" 79"FW "V" Torsion Axles

3 sizes available

3" x 3" 79"FW Straight Torsion Axles

2 sizes available

3" x 3" FW 86" Straight Torsion Axles

AX[STR]3X3 W/5LUG 86FRM ASSY

4" x 4" 79"FW Straight Torsion Axles

7 sizes available

5 Lug Hubs

2 sizes available

5Lug Hub Assemblies

HUB ASSY 1-3/8X1-1/16 5L

6Lug Hub Assemblies

2 sizes available

6Lug Hub Assemblies (Copy)

3 sizes available

8Lug Hub Assemblies

2 sizes available

Actuators for 3" Tongues, In-Line

6K# 3HOLE ACTUATOR

Actuators for 3" Tongues, In-Line W/Swing

6K# ACTUATOR W/SWING

Bearing Kits & Conversion Kits

HD 1-3/4"X1-1/4" UFP

Kit Includes: Part Description Qty PE1550 BEARING HD 1-1/4" [15123] 1 PE1600 BEARING 1-3/4" [25580] 1 PE1850 RACE-HD 1-1/4" [15245] 1 PE1900 RACE 1-3/4" [25520] 1 PE2101 SEAL 1-3/4"[UFP][21333] 1 PH2012 COTTER PIN 1/8"X1-1/4"[UFP AXLE] 1

Bearing Protector Bras

2 sizes available

Bearing Protectors

4 sizes available

Desc

DISC BRAKE ASSY 10" 5L [NO CAL] EA.

UFP

includes : PD2250 LUG NUT 13/16" qty: 5 PD1400 BEARING 1-1/16" [44649] qty: 1 PD1450 BEARING 1-3/8" [68149] qty: 1 PD2055 SEAL 1-3/8"[UFP][257-168] qty: 1 PG2026-1 DISC ROTOR & HUB 10" 5L PLTD UFP bearing protectors sold separately

Dust Caps

2 sizes available

Lug Nuts

CHROME LUG NUT (MCGARD)

ML Series Spare Tire Mounts

6 sizes available

PD1300 ~ 4-LUG HUB ASSEMBLY 1-1/16"

REPRESENTATION PHOTO MAGIC TILT HUB KIT ASSEMBLY ~ PD1300 INCLUDES: 1 x HUB W/ RACE-DACRO 1-1/16" 4-LUG 4 x LUG NUT 13/16" 2 x BEARING 1-1/16" (44649) 1 x SEAL 1-1/16" (198-125) 1 x DUST CAP (1.980) 1 x COTTER PIN 1/8" x 1-3/4" PLATED DO YOU NEED BEARING PROTECTORS AND BRAS? (NOT INCLUDED) PF1054 BEARING PROTECTOR PF1060 BRA

PD1360 ~ 4-LUG HUB WITH RACE 1-1/16" COATED

REPRESENTATION PHOTO MAGIC TILT HUB WITH RACE ~ PD1360 INCLUDES RACES ALREADY INSTALLED NOT INCLUDED BEARING KIT PE1100 BEARING PROTECTOR PF1054 AND BRA PF1060

PD1600 ~ 5-LUG HUB ASSEMBLY 1-1/16" BEARINGS 1.38" ID SEAL GREASED (UFP)

REPRESENTATION PHOTO MAGIC TILT KUB KIT ASSEMBLY ~ PD1600 INCLUDES: 1 x HUB ZINC W/ RACES 5-LUG 5 x LUG NUT 13/16" 2 x BEARING 1-1/16" (44649) 1 x SEAL 1-1/16" UFP (198-138) 1 x DUST CAP 1" (1.980) 1 x COTTER PIN 1/8" x 1-3/4" PLATED DO YOU NEED? (NOT INCLUDED) PF1054 BEARING PROTECTOR PF1060 BRA

PD1602-L ~ 5-LUG HUB ASSEMBLY 1-1/16" BEARINGS 1.25" ID SEAL GREASED (UFP & NON-UFP)

REPRESENTATION PHOTO MAGIC TILT PRE-GREASED HUB ASSEMBLY ~ PD1602-L APPLICATION: ALL 1-1/2" x 1-1/2" AXLES USING 1-1/16" BEARINGS AND 1.25" ID SEAL (UFP AND NON-UFP) ALL 2" x 2" 1,500 TO 2,500-POUND UFP AXLES FROM 2022 ON COMES PRE-GREASED AND ASSEMBLED - READY TO USE IF YOU HAVE A 2" x 2" UFP AXLE THAT USES 1-1/16" BEARINGS A 1.38" ID SEAL, USE PD1600 HUB KIT. INCLUDES: 1 x PD1670 GALV HUB 5 x PD2250 LUG NUT 1/2" 2 x PE1400 BEARING 1-1/16" (44649) (INSTALLED) 2 x PE1710 RACE (44610) (INSTALLED) 1 x PE2010 SEAL 1.98" OD x 1.25" ID (INSTALLED) 1 x PE2301 POSI-LUBE DUST CAP 1.98" 1 x PE2311 POSI-LUBE RUBBER PLUG 1 x PH2014 COTTER PIN 1/8" x 1-3/4" PLATED DO YOU NEED? (NOT INCLUDED) PF1054 BEARING PROTECTOR PF1060 BRA

PD1602-L-100 ~ 5-LUG HUB ASSEMBLY 1-1/16" BEARINGS 1.25" ID SEAL GREASED (UFP & NON-UFP)

PALLET OF 100

PD1602-L Quantity of 100 Palletized

PD1670 ~ 5-LUG HUB WITH RACE 1-1/16" GALVANIZED

REPRESENTATION PHOTO MAGIC TILT HUB W/ RACE ~ PD1670 INCLUDES RACES ALREADY INSTALLED NOT INCLUDED BEARING PROTECTOR PF1054 AND BRA PF1060

PD1700-L ~ 5-LUG HUB ASSEMBLY 1-1/16"x1-3/8" GREASED (UFP)

Magic Tilt Pre-Greased Hub Assembly ~ PD1700-L Any Axle Using 1-1/16" x 1-3/8" Bearings and a seal with 1.68" ID Included in this kit: 1 x PD1760 Galv Hub 5 x PD2250 Lug Nut 1/2" 1 x PE1400 Bearing 1-1/16" (44649) (Installed) 1 x PE1450 Bearing 1-3/8" (68149) (Installed) 1 x PE1710 Race (44610) (Installed) 1 x PE1750 Race (68111) (Installed) 1 x PE2055 Seal 2.561" OD x 1.687" ID (Installed) 1 x PE2301 Posi-Lube Dust Cap 1.98" 1 x PE2311 Posi-Lube Rubber Plug 1 x PH2012 Cotter Pin 1/8" x 1-1/4" Plated Good to know: Comes pre-greased and assembled - ready to use Need? (sold separately) PF1054 Bearing Protector PF1060 Bra

PD1702-L ~ 5-LUG HUB ASSEMBLY 1-1/16"x1-3/8" GREASED (NON UFP)

REPRESENTATION PHOTO MAGIC TILT PRE-GREASED HUB ASSEMBLY ~ PD1702-L INCLUDES: 1 x PD1760 GALV HUB 5 x PD2250 LUG NUT 1/2" 1 x PE1400 BEARING 1-1/16" (44649) (INSTALLED) 1 x PE1450 BEARING 1-3/8" (68149) (INSTALLED) 1 x PE1710 RACE (44610) (INSTALLED) 1 x PE1750 RACE (68111) (INSTALLED) 1 x PE2050 SEAL 2.565" OD x 1.719" ID (INSTALLED) 1 x PE2301 POSI-LUBE DUST CAP 1.98" 1 x PE2311 POSI-LUBE RUBBER PLUG 1 x PH2014 COTTER PIN 1/8" x 1-3/4" PLATED COMES PRE-GREASED AND ASSEMBLED - READY TO USE DO YOU NEED? (NOT INCLUDED) PF1054 BEARING PROTECTOR PF1060 BRA

PD1702-L-100 ~ 5-LUG HUB ASSEMBLY 1-1/16"x1-3/8" GREASED (NON UFP)

PALLET OF 100

PD1760 ~ 5-LUG HUB WITH RACE 1-1/16" x 1-3/8" GALVANIZED

REPRESENTATION PHOTO MAGIC TILT HUB W/ RACE ~ PD1760 INCLUDES RACES ALREADY INSTALLED NOT INCLUDED BEARING KIT PE1152 (UFP), PE1150 (NON-UFP) BEARING PROTECTOR PF1054 AND BRA PF1060

PD1857 ~ 6-LUG HUB WITH RACE 1-1/4" x 1-3/4" GALVANIZED

REPRESENTATION PHOTO MAGIC TILT HUB WITH RACE ~ PD1857 INCLUDES RACES ALREADY INSTALLED NOT INCLUDED USE BEARING KITS PE1201 (UFP AXLES) OR PE1250 (NON-UFP AXLES) BEARING PROTECTOR PF1101 AND BRA PF1063

PD1860 ~ 8-LUG HUB WITH RACES 1-1/4" x 1-3/4" GALVANIZED

REPRESENTATION PHOTO MAGIC TILT HUB WITH RACE ~ PA1860 INCLUDES RACES ALREADY INSTALLED NOT INCLUDED USE BEARING KITS PE1256 (UFP), PE1255 (NON-UFP) BEARING PROTECTOR PF1103 AND BRA PF1063

PD1861-L ~ 8-LUG HUB ASSEMBLY 1-1/4"x1-3/4" GREASED (NON-UFP)

REPRESENTATION PHOTO MAGIC TILT PRE-GREASED HUB ASSEMBLY ~ PD1861-L ALL 6K TO 7K AXLES THAT USE A 2.23" ID SEAL AND A 1" CASTLE NUT INCLUDES: 1 x PD1860 GALV HUB W/ LONG STUDS 8 x PD2250 LUG NUT 1/2" 1 x PE1555 BEARING 1-1/4" (14125A) (INSTALLED) 1 x PE1600 BEARING 1-3/4" (25580) (INSTALLED) 1 x PE1855 RACE OUTER (14276) (INSTALLED) 1 x PE1900 RACE INNER (25520) (INSTALLED) 1 x PE2100 SEAL 3.38" OD x 2.23" ID (22333) (INSTALLED) 1 x PE2308 POSI-LUBE DUST CAP 2.717" 1 x PE2311 POSI-LUBE RUBBER PLUG 1 x PH1340 COTTER PIN 1/8" x 1-3/4" PLATED COMES PRE-GREASED AND ASSEMBLED - READY TO USE

PD2250 ~ LUG NUT 1/2"

REPRESENTATION PHOTO MAGIC TILT LUG NUT ~ PD2250 SOLD INDIVIDUALLY

PD2255 ~ LUG NUT ACORN 1/2" STAINLESS STEEL

REPRESENTATION PHOTO MAGIC TILT ACORN LUG NUT~ PD2255 SOLD INDIVIDUALLY

PD2450-L ~ 6-LUG HUB ASSEMBLY 1-1/4"x1-3/4" GREASED (NON UFP)

REPRESENTATION PHOTO MAGIC TILT PRE-GREASED HUB ASSEMBLY ~ PD2450-L INCLUDES: 1 x PD1857 GALV HUB W/ LONG STUDS 6 x PD2250 LUG NUT 1/2" 1 x PE1550 BEARING 1-1/4" (15123) (INSTALLED) 1 x PE1600 BEARING 1-3/4" (25580) (INSTALLED) 1 x PE1850 RACE OUTER (15245) (INSTALLED) 1 x PE1900 RACE INNER (25520) (INSTALLED) 1 x PE2100 SEAL 3.38" OD x 2.25" ID (22333) (INSTALLED) 1 x PE2303 POSI-LUBE DUST CAP 2.441" 1 x PE2311 POSI-LUBE RUBBER PLUG 1 x PH2014 COTTER PIN 1/8" x 1-3/4" PLATED COMES PRE-GREASED AND ASSEMBLED - READY TO USE DO YOU NEED? (NOT INCLUDED) PF1101 BEARING PROTECTOR PF1063 BRA

PD2550-L ~ 6-LUG HUB ASSEMBLY 1-1/4"x1-3/4" GREASED (UFP)

REPRESENTATION PHOTO MAGIC TILT PRE-GREASED HUB ASSEMBLY ~ PD2550-L ANY AXLE USING 1-1/4" x 1-3/4" BEARINGS, A SEAL WITH 2.125" ID, PH2130 HARDWARE INCLUDES: 1 x PD1857 GALV HUB W/ 2" LONG STUDS 6 x PD2250 LUG NUT 1/2" 1 x PE1550 BEARING 1-1/4" (151123) (INSTALLED) 1 x PE1600 BEARING 1-3/4" (25580) (INSTALLED) 1 x PE1850 RACE OUTER (15245) (INSTALLED) 1 x PE1900 RACE INNER (25520) (INSTALLED) 1 x PE2101 SEAL 3.38" OD x 2.125" ID (21333) (INSTALLED) 1 x PE2303 POSI-LUBE DUST CAP 2.441" 1 x PE2311 POSI-LUBE RUBBER PLUG 1 x PH2012 COTTER PIN 1/8" x 1-1/4" PLATED COMES PRE-GREASED AND ASSEMBLED - READY TO USE

PD2750 ~ 5-LUG MAINTENANCE-FREE HUB ASSEMBLY KNOTT (KARAVAN 200-00036-SP2)

REPRESENTATION PHOTO MAGIC TILT KNOTT HUB ASSEMBLY ~ PD2750 INCLUDES: 1 X GALVANIZED HUB WITH SEALED BEARINGS 5 X LUG NUTS PLATED 1 X CRUSH SPINDLE NUT 1 X DUST CAP 1 X DUST CAP O-RING PLEASE NOTE NEVER REUSE THE OLD AXLE NUT TIGHTEN THE NEW AXLE NUT TO 207 FT-LBS (280 NM)

PE1100 ~ BEARING KIT 1-1/16" x 1-1/16" (NON-UFP)

REPRESENTATION PHOTO MAGIC TILT BEARING KIT ~ PE1100 USE WITH HUBS PD1360 , PD1670 , PD1660 INCLUDES: 2 x PE1400 BEARING 1-1/16" (44649) 2 x PE1710 RACE 1" OR 1-1/16" (44610) 1 x PE2010 SEAL 1-1/16" (198-125) 1 x PH2014 COTTER PIN 1/8" x 1-3/4" PLATED

PE1101 ~ BEARING KIT 1-1/16 x 1-1/16" (UFP)

REPRESENTATION PHOTO MAGIC TILT BEARING KIT ~ PE1101 USE WITH HUBS PD1670 , PD1660 INCLUDES: 2 x PE1400 BEARING 1-1/16" (44649) 2 x PE1710 RACE 1" OR 1-1/16" (44610) 1 x PE2015 SEAL 1-1/16" UFP (198-138) 1 x PH2012 COTTER PIN 1/8" x 1-1/4" UFP PLATED

PE1150 ~ BEARING KIT 1-1/16" x 1-3/8" (NON-UFP)

REPRESENTATION PHOTO MAGIC TILT BEARING KIT ~ PE1150 USE WITH HUBS PD1750 , PD1760 INCLUDES: 1 x PE1400 BEARING 1-1/16" (44649) 1 x PE1450 BEARING 1-3/8" (68149) 1 x PE1710 RACE 1" OR 1-1/16" (44610) 1 x PE1750 RACE 1-3/8" UCF (68111) 1 x PE2050 SEAL 1-3/8" (255-171) 1 x PH2014 COTTER PIN 1/8" x 1-3/4" PLATED

PE1151 ~ BEARING KIT 1-1/16" x 1-3/8" (UFP)

Magic Tilt Bearing Kit ~ PE1151 Good to know: Use with rotor/hub combinations PG2026-1 , PG2026-2, PG2024 Inner Race (PE1749) Used Exclusively In 5-Lug UFP 1-Piece Disk Brake Rotors Kit Contains: 1 x PE1400 Bearing 1-1/16" (44649) 1 x PE1450 Bearing 1-3/8" (68149) 1 x PE1710 Race 1" Or 1-1/16" (44610) 1 x PE1749 Race 1-3/8" UFP (68110) 1 x PE2055 Seal 1-3/8" UFP (257-168) 1 x PH2012 Cotter Pin 1/8" x 1-1/4" UFP

PE1152 ~ BEARING KIT 1-1/16" x 1-3/8" (UFP)

REPRESENTATION PHOTO MAGIC TILT BEARING KIT ~ PE1152 USE WITH HUBS PD1750 , PD1760 INCLUDES: 1 x PE1400 BEARING 1-1/16" (44649) 1 x PE1450 BEARING 1-3/8" (68149) 1 x PE1710 RACE 1" OR 1-1/16" (44610) 1 x PE1750 RACE 1-3/8" UCF (68111) 1 x PE2055 SEAL 1-3/8" UFP (257-168) 1 x PH2012 COTTER PIN 1/8" x 1-1/4" UFP

PE1200 ~ BEARING KIT 1-1/4" x 1-3/4" SELECT 6-LUG UFP HUBS/ROTORS

REPRESENTATION PHOTO MAGIC TILT BEARING KIT ~ PE1200 APPLICATION: - USE ROTORS PG2027-1 & PG2027-2 PRIOR TO 3/24 WITH 2.328" DUST CAPS - 5,200-POUND UFP AXLES (2"x3" SPRING AND 3-1/2" TORSION) USING SEAL WITH 2.13" INSIDE DIAMETER INCLUDES: 1 x PE1500 1-1/4" BEARING (67048) 1 x PE1600 1-3/4" BEARING (25580) 1 x PE1800 RACE (67010) 1 x PE1900 RACE (25520) 1 x PE2101 SEAL (21333) 1 x PH2012 1/8" x 1-1/4" COTTER PIN

PE1201 ~ BEARING KIT 1-1/4" x 1-3/4" SELECT 6-LUG UFP HUBS/ROTORS

REPRESENTATION PHOTO MAGIC TILT BEARING KIT ~ PE1201 APPLICATION: - USE WITH HUB PD1857 , ROTORS PG2027-1 & PG2027-2 (AFTER 3/24 WITH 2.44" DUST CAPS) ON UFP AXLES - 5,200-POUND UFP AXLES (2"x3" SPRING AND 3-1/2" TORSION) USING 2.13" INSIDE DIAMETER SEALS - SELECT 6-LUG NON-UFP HUBS (D-MAX, KODIAK, DRUM) ON UFP AXLES USING 2.13" INSIDE DIAMETER SEALS INCLUDES: 1 x PE1550 1-1/4" BEARING (15123) 1 x PE1600 1-3/4" BEARING (25580) 1 x PE1850 RACE (15245) 1 x PE1900 RACE (25520) 1 x PE2101 SEAL (21333) 1 x PH2012 1/8" x 1-1/4" COTTER PIN

PE1250 ~ BEARING KIT 1-1/4" x 1-3/4" SELECT 6-LUG NON-UFP HUBS/ROTORS

REPRESENTATION PHOTO MAGIC TILT BEARING KIT ~ PE1250 APPLICATION: - USE WITH HUB PD1857 AND ROTORS PG2027-1 & PG2027-2 (AFTER 3/24 WITH 2.44" DUST CAPS) ON NON-UFP AXLES - 5,200-POUND NON-UFP AXLES (2"x3" SPRING AND 3-1/2" TORSION) USING SEAL WITH 2.23" INSIDE DIAMETER - SELECT 6-LUG NON-UFP HUBS (D-MAX, KODIAK, DRUM) ON NON-UFP AXLES ON AXLES USING A SEAL WITH 2.23" INSIDE DIAMETER INCLUDES: 1 x PE1550 BEARING HD 1-1/4" (15123) 1 x PE1600 BEARING 1-3/4" (25580) 1 x PE1850 RACE HD 1-1/4" (15245) 1 x PE1900 RACE 1-3/4" (25520) 1 x PE2100 SEAL 1-3/4" (22333) 1 x PH2014 COTTER PIN 1/8" x 1-3/4" PLATED

PE1255 ~ BEARING KIT 1-1/4" x 1-3/4" 8-LUG NON-UFP HUBS

REPRESENTATION PHOTO MAGIC TILT BEARING KIT ~ PE1255 USE WITH 8-LUG HUB PD1860 OR ROTORS PG2028-1 AND PG2028-2 ON NON-UFP AXLES INCLUDES: 1 x PE1555 BEARING 1-1/4" (14125A) 1 x PE1600 BEARING 1-3/4" (25580) 1 x PE1855 RACE 1-1/4" 8-LUG (14276) 1 x PE1900 RACE 1-3/4" (25520) 1 x PE2100 SEAL 1-3/4" (22333) 1 x PH2014 COTTER PIN 1/8" x 1-3/4" PLATED

PE1256 ~ BEARING KIT 1-1/4" x 1-3/4" 8-LUG UFP HUBS

REPRESENTATION PHOTO MAGIC TILT BEARING KIT ~ PE1256 USE WITH 8-LUG HUB PD1860 OR ROTORS PG2028-1 AND PG2028-2 ON UFP AXLES INCLUDES: 1 x PE1555 BEARING 1-1/4" (14125A) 1 x PE1600 BEARING 1-3/4" (25580) 1 x PE1855 RACE 1-1/4" 8-LUG (14276) 1 x PE1900 RACE 1-3/4" (25520) 1 x PE2101 UFP SEAL 1-3/4" (21333) 1 x PH2012 x COTTER PIN 1/8" x 1-1/4" (UFP AXLE)

PE1400 ~ BEARING 1-1/16" (44649)

REPRESENTATION PHOTO MAGIC TILT BEARING ~ PE1400 SOLD INDIVIDUALLY

PE1450 ~ BEARING 1-3/8" (68149)

REPRESENTATION PHOTO MAGIC TILT BEARING ~ PE1450 SOLD INDIVIDUALLY

PE1500 ~ BEARING 1-1/4" (67048)

REPRESENTATION PHOTO MAGIC TILT BEARING ~ PE1500 SOLD INDIVIDUALLY

PE1550 ~ BEARING 1-1/4" (15123)

REPRESENTATION PHOTO MAGIC TILT H.D. BEARING ~ PE1550 SOLD INDIVIDUALLY

PE1555 ~ BEARING 1-1/4" (14125A)

REPRESENTATION PHOTO MAGIC TILT BEARING ~ PE1555 SOLD INDIVIDUALLY FOR 8 LUG HUBS

PE1600 ~ BEARING 1-3/4" (25580)

REPRESENTATION PHOTO MAGIC TILT BEARING ~ PE1600 SOLD INDIVIDUALLY

PE1710 ~ RACE 1-1/16" (44610)

REPRESENTATION PHOTO MAGIC TILT RACE ~ PE1710 SOLD INDIVIDUALLY

PE1749 ~ RACE 1-3/8" (68110)

REPRESENTATION PHOTO MAGIC TILT RACE ~ PE1749 SOLD INDIVIDUALLY

PE1750 ~ RACE 1-3/8" (68111)

REPRESENTATION PHOTO MAGIC TILT RACE ~ PE1750 SOLD INDIVIDUALLY

PE1800 ~ RACE 1-1/4" (67010)

REPRESENTATION PHOTO MAGIC TILT RACE ~ PE1800 SOLD INDIVIDUALLY

PE1850 ~ RACE 1-1/4" (15245)

REPRESENTATION PHOTO MAGIC TILT H.D. RACE ~ PE1850 SOLD INDIVIDUALLY FOR 6 LUG HEAVY DUTY NON-UFP HUBS

PE1855 ~ RACE 1-1/4" (14276)

REPRESENTATION PHOTO MAGIC TILT RACE ~ PE1855 SOLD INDIVIDUALLY FOR 8 LUG HUBS

PE1900 ~ RACE 1-3/4" (25520)

REPRESENTATION PHOTO MAGIC TILT RACE ~ PE1900 SOLD INDIVIDUALLY

PE2311 ~ CENTER HOLE CAP RUBBER PLUG (POSI-LUBE)

REPRESENTATION PHOTO MAGIC TILT RUBBER PLUG FOR POSI-LUBE DUST CAPS ~ PE2311 SOLD INDIVIDUALLY FITS ALL MODERN POSI-LUBE DUST CAPS OLDER POSI-LUBE DUST CAPS FOR 6 AND 8-LUG HUBS ONCE USED A LARGER PLUG. ALL NEWER DUST CAPS USE THIS UNIVERSAL PLUG.

PG1030 COMPLETE 5-LUG DISC BRAKE KIT ≤7.5K TOP-MOUNT (DEXTER / UFP)

REPRESENTATION PHOTO IF YOU WANT TO ADD BRAKES TO A TRAILER THAT WAS NEVER EQUIPPED WITH THEM, MAKE SURE THERE IS AT LEAST FOUR-INCHES OF CLEARANCE FROM THE BRAKE MOUNTING PLATE ON THE AXLE OR TORSION ARM TO THE OUTSIDE EDGE OF THE FRAME. MAGIC TILT BRAKE KIT ~ PG1030 NEW TOP-MOUNT ACTUATOR REPLACES THE PG1088 INLINE 3-HOLE ACTUATOR ON 3" TALL TONGUES. NEW HOLES WILL NEED TO BE DRILLED IN THE TRAILER TONGUE. COMES WITH PG4856 DOUBLE BANJO FITTING TO CONNECT BRAKE LINES. UFP SPINDLE MOUNTING HARDWARE (NOT INCLUDED): PH2125 IF USING ON NON-UFP AXLES WITH 1" SPINDLE THREADS YOU WILL NEED THE PH2160 CONVERSION KIT (NOT INCLUDED). ADDITIONAL AXLE(S) BRAKE KIT PG1040 (NOT INCLUDED) INCLUDES: 2 x BEARING 1-1/16" (44649) 2 x BEARING 1-3/8" (68149) 2 x SEAL 1-3/8" UFP (257-168) 1 x BEARING PROTECTOR SET SS 1.980 1 x PG1072 ACTUATOR TOP MOUNT DISC DEMCO #7,000 1 x HYDRAULIC BRAKE HOSE W/ SWIVEL 8' 1 x HYDRAULIC BRAKE HOSE W/ SWIVEL 23' 2 x PG2026-1 DISC ROTOR AND HUB 10" 5-LUG UFP 1 x CALIPER FITTING PLUG UFP #32212 1 x PG5003 DISC BRAKE CALIPER ASSEMBLY LH UFP DB3 (DOUBLE BANJO FITTING) 1 x PG5005 DISC BRAKE CALIPER ASSEMBLY RH UFP DB3 (DOUBLE BANJO FITTING) 4 x 7/16" x 1" SHCS BOLT UFP DISC CALIPER 1 x PL2128 5-WAY FULL GROUND WIRE HARNESS 30' 6 x PLASTIC WIRE TIE HD 14-1/2" 2 x 1/4" CHAIN W/ ONE HOOK 40" 3 x CAPSCREW PLATED NC 1/2 x 4-1/2 GR5 3 x NUT LOCK NI 1/2-13 PLATED OWNERS MANUAL

PG1031 COMPLETE 5-LUG DISC BRAKE KIT ≤7.5K IN-LINE (DEXTER / UFP)

REPRESENTATION PHOTO IF YOU WANT TO ADD BRAKES TO A TRAILER THAT WAS NEVER EQUIPPED WITH THEM, MAKE SURE THERE IS AT LEAST FOUR-INCHES OF CLEARANCE FROM THE BRAKE MOUNTING PLATE ON THE AXLE OR TORSION ARM TO THE OUTSIDE EDGE OF THE FRAME. MAGIC TILT BRAKE KIT ~ PG1031 COMES WITH PG4856 DOUBLE BANJO FITTING TO CONNECT BRAKE LINES. IF USING ON NON-UFP AXLES WITH 1" SPINDLE THREADS YOU WILL NEED THE PH2160 CONVERSION KIT (NOT INCLUDED) UFP SPINDLE MOUNTING HARDWARE (NOT INCLUDED): PH2125 ADDITIONAL AXLE(S) BRAKE KIT PG1040 (NOT INCLUDED) INCLUDES: 2 x BEARING 1-1/16" (44649) 2 x BEARING 1-3/8" (68149) 2 x SEAL 1-3/8" UFP (257-168) 1 x BEARING PROTECTOR SET SS 1.980 1 x PG1090 ACTUATOR IN-LINE DISC UFP #7500 1 x HYDRAULIC BRAKE HOSE W/ SWIVEL 8' 1 x HYDRAULIC BRAKE HOSE W/ SWIVEL 23' 2 x PG2026-1 DISC ROTOR AND HUB 10" 5-LUG UFP 1 x CALIPER FITTING PLUG UFP #32212 1 x PG5003 DISC BRAKE CALIPER ASSEMBLY LH UFP DB3 (DOUBLE BANJO FITTING) 1 x PG5005 DISC BRAKE CALIPER ASSEMBLY RH UFP DB3 (DOUBLE BANJO FITTING) 4 x 7/16" x 1" SHCS BOLT UFP DISC CALIPER 1 x PL2128 5-WAY FULL GROUND WIRE HARNESS 30' 6 x PLASTIC WIRE TIE HD 14-1/2" 2 x 1/4" CHAIN W/ ONE HOOK 40" 4 x CAPSCREW PLATED NC 1/2 x 4-1/2 GR5 4 x NUT LOCK NI 1/2-13 PLATED OWNERS MANUAL

PG1033 COMPLETE 5-LUG DISC BRAKE KIT 7.5K TO 16K (DEXTER / UFP)

REPRESENTATION PHOTO IF YOU WANT TO ADD BRAKES TO A TRAILER THAT WAS NEVER EQUIPPED WITH THEM, MAKE SURE THERE IS AT LEAST FOUR-INCHES OF CLEARANCE FROM THE BRAKE MOUNTING PLATE ON THE AXLE OR TORSION ARM TO THE OUTSIDE EDGE OF THE FRAME. MAGIC TILT BRAKE KIT ~ PG1033 COMES WITH PG4856 DOUBLE BANJO FITTING TO CONNECT BRAKE LINES. UFP SPINDLE MOUNTING HARDWARE (NOT INCLUDED): PH2125 IF USING ON NON-UFP AXLES WITH 1" SPINDLE THREADS YOU WILL NEED THE PH2160 CONVERSION KIT (NOT INCLUDED) ADDITIONAL AXLE(S) BRAKE KIT PG1040 (NOT INCLUDED) INCLUDES: 2 x BEARING 1-1/16" (44649) 2 x BEARING 1-3/8" (68149) 2 x SEAL 1-3/8" UFP (257-168) 2 x BEARING PROTECTOR 1.980 STAINLESS 1 x PG1095 ACTUATOR IN-LINE DISC #16,000 1 x HYDRAULIC BRAKE HOSE W/ SWIVEL 8' 1 x HYDRAULIC BRAKE HOSE W/ SWIVEL 23' 2 x PG2026-1 DISC ROTOR AND HUB 10" 5-LUG UFP 1 x CALIPER FITTING PLUG UFP #32212 1 x PG5003 DISC BRAKE CALIPER ASSEMBLY LH UFP (DOUBLE BANJO FITTING) 1 x PG5005 DISC BRAKE CALIPER ASSEMBLY RH UFP (DOUBLE BANJO FITTING) 4 x 7/16" x 1" CALIPER BOLT UFP 1 x PL2128 5-WAY HARNESS 30' 6 x PLASTIC WIRE TIE HD 14-1/2" 2 x 1/4" CHAIN W/ ONE HOOK 40" 4 x CAPSCREW PLATED NC 1/2 x 4-1/2 GR5 4 x NUT LOCK NI 1/2-13 PLATED OWNERS MANUAL

PG1037 COMPLETE 6-LUG DISC BRAKE KIT 10K TO 16K (DEXTER / UFP)

REPRESENTATION PHOTO IF YOU WANT TO ADD BRAKES TO A TRAILER THAT WAS NEVER EQUIPPED WITH THEM, MAKE SURE THERE IS AT LEAST FOUR-INCHES OF CLEARANCE FROM THE BRAKE MOUNTING PLATE ON THE AXLE OR TORSION ARM TO THE OUTSIDE EDGE OF THE FRAME. MAGIC TILT BRAKE KIT ~ PG1037 COMES WITH PG4856 DOUBLE BANJO FITTING TO CONNECT BRAKE LINES. UFP SPINDLE MOUNTING HARDWARE (NOT INCLUDED): PH2130 IF USING ON NON-UFP AXLES WITH 1" SPINDLE THREADS YOU WILL NEED THE PH2165 CONVERSION KIT (NOT INCLUDED) ADDITIONAL AXLE(S) BRAKE KIT PG1042 (NOT INCLUDED) INCLUDES: 2 x BEARING 1-1/4" UFP 2 x BEARING 1-3/4" UFP (25580) 2 x SEAL 1-3/4" UFP (21333) 2 x PF1101 STAINLESS BEARING PROTECTOR 2.441" 1 x PG1095 ACTUATOR DISC UFP #16,000 1 x HYDRAULIC BRAKE HOSE W/ SWIVEL 8' 1 x HYDRAULIC BRAKE HOSE W/ SWIVEL 23' 2 x PG2027-1 DISC ROTOR AND HUB 12" 6-LUG UFP 1 x CALIPER FITTING PLUG UFP #32212 1 x PG5003 DISC BRAKE CALIPER ASSEMBLY LH UFP DB3 (DOUBLE BANJO FITTING) 1 x PG5005 DISC BRAKE CALIPER ASSEMBLY RH UFP DB3 (DOUBLE BANJO FITTING) 4 x DISC CALIPER BOLT 7/16" x 1" SHCS (UFP) 1 x PL2128 5-WAY FULL GROUND WIRE HARNESS 30' 6 x PLASTIC WIRE TIE HD 14-1/2" 2 x CHAIN W/ ONE HOOK 40" 4 x CAPSCREW PLATED NC 1/2" x 4-1/2" GR5 4 x NUT LOCK NI 1/2-13 PLATED OWNERS MANUAL

PG1038 COMPLETE 8-LUG DISC BRAKE KIT 12K TO 20K (DEXTER / UFP)

REPRESENTATION PHOTO IF YOU WANT TO ADD BRAKES TO A TRAILER THAT WAS NEVER EQUIPPED WITH THEM, MAKE SURE THERE IS AT LEAST FOUR-INCHES OF CLEARANCE FROM THE BRAKE MOUNTING PLATE ON THE AXLE OR TORSION ARM TO THE OUTSIDE EDGE OF THE FRAME. MAGIC TILT BRAKE KIT ~ PG1038 TANDEM 8,000-POUND (8-LUG) AXLE TRAILERS COMES WITH PG4856 DOUBLE BANJO FITTING TO CONNECT BRAKE LINES. UFP SPINDLE MOUNTING HARDWARE (NOT INCLUDED): PH2130 IF USING ON NON-UFP AXLES WITH 1" SPINDLE THREADS YOU WILL NEED THE PH2165 CONVERSION KIT (NOT INCLUDED) ADDITIONAL AXLE(S) BRAKE KIT PG1044 (NOT INCLUDED) INCLUDES: 2 x BEARING 1-1/4" UFP 2 x BEARING 1-3/4" UFP (25580) 2 x SEAL 1-3/4" UFP (21333) 1 x BEARING PROTECTOR SET SS 2.717 1 x PG1096 DEMCO ACTUATOR DISC #20000 1 x HYDRAULIC BRAKE HOSE W/ SWIVEL 8' 1 x HYDRAULIC BRAKE HOSE W/ SWIVEL 23' 2 x PG2028-1 DISC ROTOR AND HUB 12" 8-LUG UFP 1 x CALIPER FITTING PLUG UFP #32212 1 x PL2142 5-WAY FULL GROUND WIRE HARNESS 40' 1 x PG5003 DISC BRAKE CALIPER ASSEMBLY LH UFP DB3 (DOUBLE BANJO FITTING) 1 x PG5005 DISC BRAKE CALIPER ASSEMBLY RH UFP DB3 (DOUBLE BANJO FITTING) 4 x DISC CALIPER BOLT 7/16" x 1" SHCS (UFP) 6 x PLASTIC WIRE TIE HD 14-1/2" 2 x CHAIN W/ ONE HOOK 40" 4 x CAPSCREW PLATED NC 1/2" x 4-1/2" GR5 4 x NUT LOCK NI 1/2-13 PLATED OWNERS MANUAL

PG1040 ADDITIONAL AXLE 5-LUG DISC BRAKE KIT (DEXTER / UFP)

REPRESENTATION PHOTO IF YOU WANT TO ADD BRAKES TO A TRAILER THAT WAS NEVER EQUIPPED WITH THEM, MAKE SURE THERE IS AT LEAST FOUR-INCHES OF CLEARANCE FROM THE BRAKE MOUNTING PLATE ON THE AXLE OR TORSION ARM TO THE OUTSIDE EDGE OF THE FRAME. MAGIC TILT BRAKE KIT ~ PG1040 COMES WITH PG4856 DOUBLE BANJO FITTING TO CONNECT BRAKE LINES. UFP SPINDLE MOUNTING HARDWARE (NOT INCLUDED): PH2125 IF USING ON NON-UFP AXLES WITH 1" SPINDLE THREADS YOU WILL NEED THE PH2160 CONVERSION KIT (NOT INCLUDED) INCLUDES: 2 x BEARING 1-1/16" (44649) 2 x BEARING 1-3/8" (68149) 2 x SEAL 1-3/8" UFP (257-168) 1 x BEARING PROTECTOR SET SS 1.980 1 x HYDRAULIC BRAKE HOSE W/ SWIVEL 4' 1 x HYDRAULIC BRAKE HOSE W/ SWIVEL 8' 2 x PG2026-1 DISC ROTER AND HUB 10" 5-LUG UFP 1 x CALIPER FITTING PLUG UFP #32212 1 x PG5003 DISC BRAKE CALIPER ASSEMBLY LH UFP DB3 (DOUBLE BANJO FITTING) 1 x PG5005 DISC BRAKE CALIPER ASSEMBLY RH UFP DB3 (DOUBLE BANJO FITTING) 4 x DISC CALIPER BOLT 7/16" x 1" SHCS (UFP) 6 x PLASTIC WIRE TIE HD 14-1/2" OWNERS MANUAL

PG1042 ADDITIONAL AXLE 6-LUG DISC BRAKE KIT (DEXTER / UFP)

REPRESENTATION PHOTO IF YOU WANT TO ADD BRAKES TO A TRAILER THAT WAS NEVER EQUIPPED WITH THEM, MAKE SURE THERE IS AT LEAST FOUR-INCHES OF CLEARANCE FROM THE BRAKE MOUNTING PLATE ON THE AXLE OR TORSION ARM TO THE OUTSIDE EDGE OF THE FRAME. MAGIC TILT BRAKE KIT ~ PG1042 COMES WITH PG4856 DOUBLE BANJO FITTING TO CONNECT BRAKE LINES. UFP SPINDLE MOUNTING HARDWARE (NOT INCLUDED): PH2130 IF USING ON NON-UFP AXLES WITH 1" SPINDLE THREADS YOU WILL NEED THE PH2165 CONVERSION KIT (NOT INCLUDED) INCLUDES: 2 x BEARING 1-1/4" 2 x BEARING 1-3/4" (25580) 2 x SEAL 1-3/4" UFP (21333) 2 x PF1101 STAINLESS BEARING PROTECTOR 2.441" 1 x HYDRAULIC BRAKE HOSE W/ SWIVEL 4' 1 x HYDRAULIC BRAKE HOSE W/ SWIVEL 8' 2 x PG2027-1 DISC ROTER AND HUB 12" 6-LUG UFP 1 x CALIPER FITTING PLUG UFP #32212 1 x PG5003 DISC BRAKE CALIPER ASSEMBLY LH UFP DB3 (DOUBLE BANJO FITTING) 1 x PG5005 DISC BRAKE CALIPER ASSEMBLY RH UFP DB3 (DOUBLE BANJO FITTING) 4 x DISC CALIPER BOLT 7/16" x 1" SHCS (UFP) 6 x PLASTIC WIRE TIE HD 14-1/2" OWNERS MANUAL

PG1044 ADDITIONAL AXLE 8-LUG DISC BRAKE KIT (DEXTER / UFP)

REPRESENTATION PHOTO IF YOU WANT TO ADD BRAKES TO A TRAILER THAT WAS NEVER EQUIPPED WITH THEM, MAKE SURE THERE IS AT LEAST FOUR-INCHES OF CLEARANCE FROM THE BRAKE MOUNTING PLATE ON THE AXLE OR TORSION ARM TO THE OUTSIDE EDGE OF THE FRAME. MAGIC TILT BRAKE KIT ~ PG1044 COMES WITH PG4856 DOUBLE BANJO FITTING TO CONNECT BRAKE LINES. UFP SPINDLE MOUNTING HARDWARE (NOT INCLUDED): PH2130 IF USING ON NON-UFP AXLES WITH 1" SPINDLE THREADS YOU WILL NEED THE PH2165 CONVERSION KIT (NOT INCLUDED) INCLUDES: 2 x BEARING 1-1/4" 2 x BEARING 1-3/4" (25580) 2 x SEAL 1-3/4" UFP (21333) 2 x BEARING PROTECTOR 2.328 1 x HYDRAULIC BRAKE HOSE W/ SWIVEL 4' 1 x HYDRAULIC BRAKE HOSE W/ SWIVEL 8' 1 x PG2028-1 DISC ROTER AND HUB 12" 8-LUG UFP 2 x CALIPER FITTING PLUG UFP #32212 1 x PG5003 DISC BRAKE CALIPER ASSEMBLY LH UFP DB3 (DOUBLE BANJO FITTING) 1 x PG5005 DISC BRAKE CALIPER ASSEMBLY RH UFP DB3 (DOUBLE BANJO FITTING) 4 x DISC CALIPER BOLT 7/16" x 1" SHCS (UFP) 6 x PLASTIC WIRE TIE HD 14-1/2" OWNERS MANUAL

PG1090-1 ~ BRAKE LOCKOUT CLIP A-160 ACTUATOR DEXTER / UFP

REPRESENTATION PHOTO MAGIC TILT BRAKE LOCKOUT CLIP ~ PG1090-1 CAUTION! IF LOCKOUT IS NOT REMOVED DURING NORMAL TOWING THE TRAILER'S BRAKES WILL NOT FUNCTION. CUSTOMER ASSUMES RESPONSIBILITY FOR SAFE USAGE. ALLOWS TRAILERS WITH DEXTER / UFP 16K IN-LINE SURGE DISC BRAKES TO BE BACKED UP WHILE NOT PLUGGED INTO THE VEHICLE. DESIGED TO SLIP BETWEEN HOUSING AND COUPLER TO FILL THE TRAVEL SLOT.

PG2035 DISC BRAKE ASSEMBLY 8-LUG (DEXTER / UFP)

REPRESENTATION PHOTO IF YOU WANT TO ADD BRAKES TO A TRAILER THAT WAS NEVER EQUIPPED WITH THEM, MAKE SURE THERE IS AT LEAST FOUR-INCHES OF CLEARANCE FROM THE BRAKE MOUNTING PLATE ON THE AXLE OR TORSION ARM TO THE OUTSIDE EDGE OF THE FRAME. MAGIC TILT DISC BRAKE ASSEMBLY ~ PG2035 COMES WITH PG4856 DOUBLE BANJO FITTING TO CONNECT BRAKE LINES. UFP SPINDLE MOUNTING HARDWARE (NOT INCLUDED): PH2130 IF USING ON NON-UFP AXLES WITH 1" SPINDLE THREADS YOU WILL NEED THE PH2165 CONVERSION KIT (NOT INCLUDED) INCLUDES: 16 x LUG NUT 13/16" 2 x BEARING 1-1/4" (67048) 2 x BEARING 1-3/4" (25580) 2 x SEAL 1-3/4" UFP (21333) 1 x BEARING PROTECTOR SET 2.717 2 x PG2028-1 DISC ROTOR AND HUB 12" 8-LUG UFP 1 x PG5003 DISC BRAKE CALIPER ASSEMBLY LH UFP DB3 (DOUBLE BANJO FITTING) 1 x PG5005 DISC BRAKE CALIPER ASSEMBLY RH UFP DB3 (DOUBLE BANJO FITTING) 4 x 7/16" x 1" SHCS BOLT UFP DISC CALIPER 2 x COTTER PIN 1/8" x 1-1/4" UFP OWNERS MANUAL

PG2070-L ~ DISC BRAKE ASSEMBLY 5-LUG GREASED (DEXTER / UFP)

To Add brakes to a trailer that was never equipped with them, Confirm there is At least four-inches of clearance from the brake mounting plate on the axle or torsion arm to the outside edge of the frame. Magic Tilt Brake Assembly ~ PG2070-L Good to know: - Bearings, Races and seals are installed in rotors and greased (Ready-To-Go). - 2 x PE2050 Replacement Seals are in the box (Loose) To accomodate non-UFP spindles if needed. Customer is responsible for determination. - Ships with PG4856 Double banjo fittings to connect brake lines. - Includes UFP hub mounting hardware. If using on non-UFP axles with 1" Spindle Threads you'll also need the PH2160 Conversion Kit (Not Included). Included in this kit: 10 x PD2250 Lug Nut 13/16" 2 x PE1400 Bearing 1-1/16" (44649) - Installed 2 x PE1450 Bearing 1-3/8" (68149) - Installed 2 x PE2055 Seal 2.57" x 1.68" UFP (257-168) - Installed 2 x PF1054 Bearing Protector SS 1.980 2 x PF1060 Bearing Protector Bra 1.980 2 x PG2026-1 Disc Rotor And Hub 10" 5-Lug Plated UFP 1 x PG5003 Disc brake caliper assembly LH UFP db3 (Double Banjo Fitting) 1 x PG5005 Disc brake caliper assembly RH UFP db3 (Double Banjo Fitting) 4 x PG5007 Disc Caliper Bolt 7/16" x 1" Shcs (UFP) 2 x PH2012 Cotter Pin 1/8" x 1-1/4" Plated UFP 1 x PG4862 Caliper Fitting Plug Brass 2 x PH1980 Spindle Nut 13/16" UFP 2 x PH2108 Spindle Nut Retainer UFP 2 x PH2065 Axle D-Washer 3/4" x 3/32" UFP 2 x PE2050 Seal 2.55" x 1.71" Non-UFP - Loose Owners Manual

PG2071-L ~ DISC BRAKE ASSEMBLY 6-LUG GREASED (DEXTER / UFP)

REPRESENTATION PHOTO IF YOU WANT TO ADD BRAKES TO A TRAILER THAT WAS NEVER EQUIPPED WITH THEM, MAKE SURE THERE IS AT LEAST FOUR-INCHES OF CLEARANCE FROM THE BRAKE MOUNTING PLATE ON THE AXLE OR TORSION ARM TO THE OUTSIDE EDGE OF THE FRAME. MAGIC TILT DISC BRAKE ASSEMBLY ~ PG2071-L - BEARINGS, RACES AND SEALS ARE INSTALLED IN ROTORS AND GREASED (READY-TO-GO). - 2 x PE2100 REPLACEMENT SEALS ARE INCLUDED (LOOSE) TO ACCOMODATE NON-UFP SPINDLES IF NEEDED. CUSTOMER IS RESPONSIBLE FOR DETERMINATION. - COMES WITH PG4856 DOUBLE BANJO FITTING TO CONNECT BRAKE LINES. - INCLUDES UFP HUB MOUNTING HARDWARE. IF USING ON NON-UFP AXLES WITH 1" SPINDLE THREADS YOU WILL NEED THE PH2165 CONVERSION KIT (NOT INCLUDED). INCLUDES: 12 x PD2250 LUG NUT 13/16" 2 x PE1550 BEARING 1-1/4" (15123) - INSTALLED 2 x PE1600 BEARING 1-3/4" (25580) - INSTALLED 2 x PE2101 SEAL 3.37" x 2.13" UFP (21333) - INSTALLED 2 x PF1101 BEARING PROTECTOR SS 2.441" 2 x PF1063 BEARING PROTECTOR BRA 2.441" 2 x PG2027-1 DISC ROTOR AND HUB 12" 6-LUG PLATED UFP 1 x PG500 3 DISC BRAKE CALIPER ASSEMBLY LH UFP DB3 (DOUBLE BANJO FITTING) 1 x PG5005 DISC BRAKE CALIPER ASSEMBLY RH UFP DB3 (DOUBLE BANJO FITTING) 4 x PG5007 DISC CALIPER BOLT 7/16" x 1" SHCS (UFP) 2 x PH2012 COTTER PIN 1/8" x 1-1/4" PLATED UFP 1 x PG4862 CALIPER FITTING PLUG BRASS 2 x PH1980 SPINDLE NUT 13/16" UFP 2 x PH2108 SPINDLE NUT RETAINER UFP 2 x PH2066 AXLE D-WASHER 3/4" x 3/16" UFP 2 x PE2100 SEAL 3.37" x 2.23" NON-UFP - LOOSE OWNERS MANUAL

PG5007 ~ DISC CALIPER BOLT 7/16" x 1" DEXTER / UFP

REPRESENTATION PHOTO MAGIC TILT CALIPER BOLT ~ PG5007 USES 3/8" ALLEN WRENCH

PG5034 ~ DISC BRAKE CALIPER 3.5

6K (DEEMAXX CALP-3-6K-MAXX)

REPRESENTATION PHOTO MAGIC TILT DISC BRAKE CALIPER ~ PG5034 APPLICATION: 3.5K 10" 5-LUG AND 6K 12" 6-LUG DEEMAXX BRAKING SYSTEMS WITH SLIP-OVER ROTORS OR ONE-PIECE HUB/ROTORS WITH CORRECT MOUNT PLATE (NOT INCLUDED) INCLUDES BRAKE PADS NOT COMPATIBLE OTHER BRAKE BRANDS

PG5058 ~ DISC BRAKE ADAPTER PLATE (DEXTER / UFP)

REPRESENTATION PHOTO MAGIC TILT ADAPTER PLATE ~ PG5058 ADAPTS 5-HOLE ROUND BRAKE PLATES TO 4-HOLE SQUARE ON 5.2K TO 7K AXLES. ALOWS DIRECT MOUNTING OF DEXTER / UFP CALIPERS ON 12" ROTORS. REQUIRES THE FOLLOWING HARDWARE (NOT INCLUDED) 5 X PY0215 3/8" x 1-1/14" BOLT 5 X PY1305 3/8" NYLOCK NUT

PH1300 ~ SPRING AXLE 2 x 2 (CUSTOM)

3.5K DEXTER / UFP

Magic Tilt Heavy duty custom spring axle no Hubs ~ PH1300 Contact us at 877-795-1965 for a shipping quote (V - Add PH0999, $27.95) V - Above Springs Only Good to know: Includes 4-Hole Square Brake Plate Axle will come with an "X" Drawn On The Tube. The x should face the back of the trailer when installed.

PH1305-1 ~ POSI-LUBE SPINDLE AXLE UPGRADE

REPRESENTATION PHOTO MAGIC TILT POSI-LUBE SPINDLE UPGRADE ~ PH1305-1 AXLES DO NOT COME STANDARD WITH THE POSI-LUBE FEATURE. THIS PART NUMBER UPGRADES THE STANDARD SPINDLES ON ONE AXLE TO POSI-LUBE. POSI-LUBE SPINDLES HAVE A GREASE FITTING ON THE END ALLOWING GREASE TO BE PUMPED TO THE BACK OF THE SPINDLE. WHILE MANY OLDER MAGIC TILT AXLES WERE BUILT WITH THIS FEATURE, IT IS NOW RECOMENDED TO USE BEARING PROTECTORS ON THE HUBS.

PH1305-2 ~ POSI-LUBE SPINDLE UPGRADE

REPRESENTATION PHOTO MAGIC TILT POSI-LUBE SPINDLE UPGRADE ~ PH1305-2 AXLES DO NOT COME STANDARD WITH THE POSI-LUBE FEATURE. THIS PART NUMBER UPGRADES THE STANDARD SPINDLES ON ONE AXLE TO POSI-LUBE. POSI-LUBE SPINDLES HAVE A GREASE FITTING ON THE END ALLOWING GREASE TO BE PUMPED TO THE BACK OF THE SPINDLE. WHILE MANY OLDER MAGIC TILT AXLES WERE BUILT WITH THIS FEATURE, IT IS NOW RECOMENDED TO USE BEARING PROTECTORS ON THE HUBS.

PH1320 ~ REMOVABLE SPINDLE 3750# TORSION DEXTER / TIE DOWN

REPRESENTATION PHOTO MAGIC TILT TORSION AXLE SPINDLE ~ PH1320 INCLUDES: 1" NUT, WASHER AND COTTER PIN FOR MOUNTING SPINDLE TO TORSION ARM DOES NOT INCLUDE FOLLOWING SPINDLE-TO-HUB HARDWARE: PH2060 SPINDLE WASHER PH2000 SPINDLE NUT PH2014 COTTER PIN USE WITH FOLLOWING HUBS (NOT INCLUDED): PD1702-L IDLER HUB KIT PG2026-1 DISC ROTOR

PH1325 ~ TORSION ARM 3" AXLES NON-POSI LUBE DEXTER / UFP

REPRESENTATION PHOTO MAGIC TILT TORSION ARM & SPINDLE ~ PH1325 CAUTION – MAKE SURE YOU PROPERLY IDENTIFY YOUR BRAND OF TORSION ARM AS UFP (SEE SECOND IMAGE) INCLUDES 4-HOLE BRAKE PLATE AND TORSION ARM MOUNTING BOLT REQUIRES THE FOLLOWING HUB MOUNTING HARDWARE KIT PH2125 (NOT INCLUDED)

PH1327 ~ TORSION ARM 3" AXLES W/ POSI-LUBE DEXTER / UFP

REPRESENTATION PHOTO MAGIC TILT TORSION ARM & SPINDLE ~ PH1327 CAUTION – MAKE SURE YOU PROPERLY IDENTIFY YOUR BRAND OF TORSION ARM AS UFP (SEE SECOND IMAGE) INCLUDES 4-HOLE BRAKE PLATE AND TORSION ARM MOUNTING BOLT REQUIRES THE FOLLOWING HUB MOUNTING HARDWARE KIT PH2125 (NOT INCLUDED)

PH1328-4

Vault Dexter (UFP) Loaded Torsion Spindle Arm 4.2K, Hub/5 Lug Rotor with Caliper Spindle Arm 002-324-08 Rotor 008-435-05 Caliper 089-235-28 Vault Cap 021-091-00 Seal 010-172-00 Mounting Bolt, Nut and Washer (5/8-11 x 4" Bolt)

PH1328-5

Vault UFP / Dexter Loaded Torsion Spindle Arm, Aluminum Caliper, Rotor 5 Lug, LEFT Hand Assembled and Pre-greased with Vault Hybrid oil. Spindle Arm 002-324-08 Rotor 008-435-05 Caliper 089-235-28 Vault Cap 021-091-00 Seal 010-172-00

PH1374 ~ TORSION AXLE 2-1/2" "V" 93T 79FW 3.8K NO HUBS DEXTER / TIE DOWN

REPRESENTATION PHOTO MAGIC TILT TORSION AXLE WITHOUT HUBS TIE DOWN ~ PH1374 ( PLEASE CALL 941-358-1117 FOR SHIPPING QUOTE) FRAME WIDTH: 80-1/2" (INSIDE MOUNT) 79" (OUTSIDE MOUNT) TRACK (HUB-FACE TO HUB-FACE): 93" INCLUDES 4-HOLE SQUARE BRAKE PLATES ADD-ONS (NOT INCLUDED) FRAME MOUNTING HARDWARE: ALUMINUM TUBE FRAME BOTTOM CHANNEL PY9145-T I-BEAM ALUMINUM FRAME PY9145 GALVANIZED TUBE FRAME U-BOLTS

PH1450 ~ CUSTOM SPRING AXLE 2x3 UP TO 89T 5-6K DEXTER / UFP

REPRESENTATION PHOTO MAGIC TILT HEAVY DUTY CUSTOM SPRING AXLE NO HUBS ~ PH1450 PLEASE CALL 941-358-1117 FOR SHIPPING QUOTE (V - ADD PH0999, $27.95) V - ABOVE SPRINGS ONLY INCLUDES 4-HOLE SQUARE BRAKE PLATES STANDARD. CAN BE ORDERED WITH 5-HOLE ROUND BRAKE PLATES AXLE WILL COME WITH AN "X" DRAWN ON THE TUBE. THE X SHOULD FACE THE BACK OF THE TRAILER WHEN INSTALLED.

PH1454 ~ TORSION AXLE 2-1/2" "V" 66-3/4T 56FW 2.1K W/HUBS KNOTT (KARAVAN 200-00049)

REPRESENTATION PHOTO MAGIC TILT TORSION AXLE W/ HUBS KNOTT ~ PH1454 TRACK (HUB FACE TO HUB FACE): 66-3/4" LUG NUTS NOT INCLUDED MOUNTING HARDWARE (NOT INCLUDED) ALUMINUM TUBE FRAME BOTTOM CHANNEL PY9145-T ALUMINUM I-BEAM FRAME PY9145 GALVANIZED TUBE FRAME U-BOLTS 74x12x10

PH1462 ~ TORSION AXLE 2-1/2" STRAIGHT 92T 81-1/2FW 3K W/ HUBS KNOTT

REPRESENTATION PHOTO MAGIC TILT TORSION AXLE WITH HUBS KNOTT ~ PH1462 ( PLEASE CALL 941-358-1117 FOR SHIPPING QUOTE) SPECIAL ORDER - PLEASE ALLOW EXTRA TIME FRAME WIDTH: 83" (INSIDE MOUNT) 81-1/2" (OUTSIDE MOUNT) TRACK (HUB FACE TO HUB FACE): 92" LUG NUTS NOT INCLUDED MOUNTING HARDWARE (NOT INCLUDED) ALUMINUM TUBE FRAME BOTTOM CHANNEL PY9145-T ALUMINUM I-BEAM FRAME PY9145 GALVANIZED TUBE FRAME U-BOLTS

PH1465 ~ TORSION AXLE 2-1/2" STRAIGHT 88-3/4T 77FW 3.8K W/ HUBS KNOTT (KARAVAN 200-200059-GL)

REPRESENTATION PHOTO MAGIC TILT TORSION AXLE WITH HUBS KNOTT ~ PH1465 ( PLEASE CALL 941-358-1117 FOR SHIPPING QUOTE) TRACK (HUB FACE TO HUB FACE): 88-3/4" LUG NUTS NOT INCLUDED MOUNTING HARDWARE (NOT INCLUDED) ALUMINUM TUBE FRAME BOTTOM CHANNEL PY9145-T I-BEAM ALUMINUM FRAME PY9145 GALVANIZED TUBE FRAME U-BOLTS

PH1500 ~ CUSTOM SPRING AXLE 2x3 UP TO 88T 3.5K DEXTER / UFP

REPRESENTATION PHOTO MAGIC TILT HEAVY DUTY CUSTOM SPRING AXLE NO HUBS ~ PH1500 PLEASE CALL 941-358-1117 FOR SHIPPING QUOTE (V - ADD PH0999, $27.95) V - ABOVE SPRINGS ONLY INCLUDES 4-HOLE SQUARE BRAKE PLATES. AXLE WILL COME WITH AN "X" DRAWN ON THE TUBE. THE X SHOULD FACE THE BACK OF THE TRAILER WHEN INSTALLED.

PH1600 ~ TORSION AXLE 3x3 (CUSTOM) 73-95T 3.5K NO HUBS (NON UFP)

REPRESENTATION PHOTO MAGIC TILT CUSTOM 3x3 TORSION AXLE NO HUBS ~ PH1600 PLEASE CALL 941-358-1117 FOR SHIPPING QUOTE SPECIAL ORDER - PLEASE ALLOW ADDITIONAL TIME FOR SHIPPING V + $22.95 (PH0999) FRAME WIDTH MUST BE 63" OR GREATER INCLUDES 4-HOLE SQUARE BRAKE PLATES. MOUNTING HARDWARE (NOT INCLUDED) ALUMINUM TUBE FRAME BOTTOM CHANNEL PY9145-T I-BEAM ALUMINUM FRAME PY9145

PH1605 ~ CUSTOM TORSION AXLE 3-1/2x3-1/2 73-95T 5-6K DEXTER/UFP

REPRESENTATION PHOTO MAGIC TILT CUSTOM 3-1/2x3-1/2 TORSION AXLE NO HUBS ~ PH1605 (PLEASE CALL 941-358-1117 FOR SHIPPING QUOTE) SPECIAL ORDER - PLEASE ALLOW ADDITIONAL TIME FOR SHIPPING V + $22.95 (PH0999) INCLUDES 4-HOLE SQUARE BRAKE PLATES STANDARD. CAN BE ORDERED WITH 5-HOLE ROUND BRAKE PLATES. MOUNTING HARDWARE TO FRAME (NOT INCLUDED) ALUMINUM TUBE FRAME BOTTOM CHANNEL PY9145-T I-BEAM ALUMINUM FRAME PY9145

PH2145 ~ HUB CONVERSION KIT 1-1/16" SPINDLES (NON-UFP HUBS to UFP AXLES)

REPRESENTATION PHOTO MAGIC TILT HUB CONVERSION KIT ~ PH2145 INCLUDES: ENOUGH HARDWARE TO CONVERT TWO HUBS TO 1-1/16" UFP-STYLE SPINDLES 2 x PE2010 SEAL 1-1/16" UFP (125-198) 2 x PH1980 SPINDLE NUT 13/16" UFP 2 x PH2012 COTTER PIN 1/8" x 1-1/4" UFP 2 x PH2065 3/4" AXLE D WASHER 3/32" UFP 2 x PH2108 SPINDLE NUT RETAINER UFP

PH2150 ~ HUB CONVERSION KIT 1-3/8" SPINDLES (NON-UFP HUBS to UFP AXLES)

REPRESENTATION PHOTO MAGIC TILT HUB CONVERSION KIT ~ PH2150 INCLUDES: ENOUGH HARDWARE TO CONVERT TWO HUBS TO 3.5K UFP-STYLE SPINDLES 2 x PE2055 SEAL 1-3/8" UFP (168-257) 2 x PH1980 SPINDLE NUT 13/16" UFP 2 x PH2012 COTTER PIN 1/8" x 1-1/4" UFP 2 x PH2065 3/4" AXLE D WASHER 3/32" UFP 2 x PH2108 SPINDLE NUT RETAINER UFP

PH2155 ~ HUB CONVERSION KIT 1-3/4" SPINDLES (NON-UFP HUBS to UFP AXLES)

REPRESENTATION PHOTO MAGIC TILT HUB CONVERSION KIT ~ PH2155 INCLUDES: ENOUGH HARDWARE TO CONVERT TWO HUBS TO ALL UFP-STYLE 1-1/4" x 1-3/4" SPINDLES 2 x PE2101 SEAL 1-3/4" UFP (21333) 2 x PH1980 SPINDLE NUT 13/16" UFP 2 x PH2012 COTTER PIN 1/8" x 1-1/4" UFP 2 x PH2066 3/4" AXLE D WASHER 3/16" UFP 2 x PH2108 SPINDLE NUT RETAINER UFP

PH2160 ~ CONVERSION KIT (5-LUG 3.5K UFP ROTORS & HUBS to NON-UFP AXLES)

REPRESENTATION PHOTO MAGIC TILT HUB/ROTOR CONVERSION KIT ~ PH2160 INCLUDES: ENOUGH HARDWARE TO CONVERT TWO 5-LUG ROTORS OR HUBS TO EITHER 1" D OR 1" ROUND SPINDLES 2 x PE2050 SEAL 1-3/8" NON-UFP (171-255) 2 x PH2014 COTTER PIN 1/8" x 1-3/4" (1" SPINDLE THREADS) 2 x PH2000 AXLE NUT 1" CASTLE NON-UFP 2 x PH2105 TANG WASHER (1" D-SPINDLES) 2 x PH2070 SPINDLE WASHER (1" D-SPINDLES) 2 x PH2060 SPINDLE WASHER (1" ROUND SPINDLES)

PH2165 ~ CONVERSION KIT (6 & 8-LUG UFP ROTORS & HUBS TO NON-UFP AXLES)

REPRESENTATION PHOTO MAGIC TILT HUB/ROTOR CONVERSION KIT ~ PH2165 INCLUDES: ENOUGH HARDWARE TO CONVERT TWO 6 OR 8-LUG ROTORS OR HUBS TO EITHER 1" D OR 1" ROUND SPINDLES 2 x PE2100 SEAL 1-3/4" NON-UFP (22333) 2 x PH2014 COTTER PIN 1/8" x 1-3/4" (1" SPINDLE THREADS) 2 x PH2000 AXLE NUT 1" CASTLE NON-UFP 2 x PH2105 TANG WASHER (1" D-SPINDLES) 2 x PH2070 SPINDLE WASHER (1" D-SPINDLES) 2 x PH2060 SPINDLE WASHER (1" ROUND SPINDLES)

PH6025

AX[V]2X2X86TR 68SC HD W/FLG [NO HUBS]

PH6049

2"X2" AXLE FOR LEAF SPRING SUSPENSION TRAILER, GALVANIZED, "V" BEND, 85" TRACK (HUB FACE), 68" SPRING CENTER, 1 3/8" X 1 1/16" TAPERED HEAVY DUTY SPINDLE. COMES WITH 5 LUG GALVANIZED HUBS, 5" ON 4.5" PATTERN.

Pro Spare Tire Mounts

2 sizes available

Torsion Arms

ARM/VAULT 5L HUB ASSY

UFP DEALER LOCKOUT

DEALER LOCKOUT -6K/7K
