10" Disc Rotors

DISC ROTOR 10" 5LUG [UFP]

4" x 4" 79"FW Straight Torsion Axles

AX[STR]4X4X81 DISC 8L ASSY

DISC BRAKE ROTOR KIT 12" 6L [NO CAL] EA.

UFP

PE1151 ~ BEARING KIT 1-1/16" x 1-3/8" (UFP)

Magic Tilt Bearing Kit ~ PE1151 Good to know: Use with rotor/hub combinations PG2026-1 , PG2026-2, PG2024 Inner Race (PE1749) Used Exclusively In 5-Lug UFP 1-Piece Disk Brake Rotors Kit Contains: 1 x PE1400 Bearing 1-1/16" (44649) 1 x PE1450 Bearing 1-3/8" (68149) 1 x PE1710 Race 1" Or 1-1/16" (44610) 1 x PE1749 Race 1-3/8" UFP (68110) 1 x PE2055 Seal 1-3/8" UFP (257-168) 1 x PH2012 Cotter Pin 1/8" x 1-1/4" UFP

PE1200 ~ BEARING KIT 1-1/4" x 1-3/4" SELECT 6-LUG UFP HUBS/ROTORS

REPRESENTATION PHOTO MAGIC TILT BEARING KIT ~ PE1200 APPLICATION: - USE ROTORS PG2027-1 & PG2027-2 PRIOR TO 3/24 WITH 2.328" DUST CAPS - 5,200-POUND UFP AXLES (2"x3" SPRING AND 3-1/2" TORSION) USING SEAL WITH 2.13" INSIDE DIAMETER INCLUDES: 1 x PE1500 1-1/4" BEARING (67048) 1 x PE1600 1-3/4" BEARING (25580) 1 x PE1800 RACE (67010) 1 x PE1900 RACE (25520) 1 x PE2101 SEAL (21333) 1 x PH2012 1/8" x 1-1/4" COTTER PIN

PE1201 ~ BEARING KIT 1-1/4" x 1-3/4" SELECT 6-LUG UFP HUBS/ROTORS

REPRESENTATION PHOTO MAGIC TILT BEARING KIT ~ PE1201 APPLICATION: - USE WITH HUB PD1857 , ROTORS PG2027-1 & PG2027-2 (AFTER 3/24 WITH 2.44" DUST CAPS) ON UFP AXLES - 5,200-POUND UFP AXLES (2"x3" SPRING AND 3-1/2" TORSION) USING 2.13" INSIDE DIAMETER SEALS - SELECT 6-LUG NON-UFP HUBS (D-MAX, KODIAK, DRUM) ON UFP AXLES USING 2.13" INSIDE DIAMETER SEALS INCLUDES: 1 x PE1550 1-1/4" BEARING (15123) 1 x PE1600 1-3/4" BEARING (25580) 1 x PE1850 RACE (15245) 1 x PE1900 RACE (25520) 1 x PE2101 SEAL (21333) 1 x PH2012 1/8" x 1-1/4" COTTER PIN

PE1250 ~ BEARING KIT 1-1/4" x 1-3/4" SELECT 6-LUG NON-UFP HUBS/ROTORS

REPRESENTATION PHOTO MAGIC TILT BEARING KIT ~ PE1250 APPLICATION: - USE WITH HUB PD1857 AND ROTORS PG2027-1 & PG2027-2 (AFTER 3/24 WITH 2.44" DUST CAPS) ON NON-UFP AXLES - 5,200-POUND NON-UFP AXLES (2"x3" SPRING AND 3-1/2" TORSION) USING SEAL WITH 2.23" INSIDE DIAMETER - SELECT 6-LUG NON-UFP HUBS (D-MAX, KODIAK, DRUM) ON NON-UFP AXLES ON AXLES USING A SEAL WITH 2.23" INSIDE DIAMETER INCLUDES: 1 x PE1550 BEARING HD 1-1/4" (15123) 1 x PE1600 BEARING 1-3/4" (25580) 1 x PE1850 RACE HD 1-1/4" (15245) 1 x PE1900 RACE 1-3/4" (25520) 1 x PE2100 SEAL 1-3/4" (22333) 1 x PH2014 COTTER PIN 1/8" x 1-3/4" PLATED

PE1255 ~ BEARING KIT 1-1/4" x 1-3/4" 8-LUG NON-UFP HUBS

REPRESENTATION PHOTO MAGIC TILT BEARING KIT ~ PE1255 USE WITH 8-LUG HUB PD1860 OR ROTORS PG2028-1 AND PG2028-2 ON NON-UFP AXLES INCLUDES: 1 x PE1555 BEARING 1-1/4" (14125A) 1 x PE1600 BEARING 1-3/4" (25580) 1 x PE1855 RACE 1-1/4" 8-LUG (14276) 1 x PE1900 RACE 1-3/4" (25520) 1 x PE2100 SEAL 1-3/4" (22333) 1 x PH2014 COTTER PIN 1/8" x 1-3/4" PLATED

PE1256 ~ BEARING KIT 1-1/4" x 1-3/4" 8-LUG UFP HUBS

REPRESENTATION PHOTO MAGIC TILT BEARING KIT ~ PE1256 USE WITH 8-LUG HUB PD1860 OR ROTORS PG2028-1 AND PG2028-2 ON UFP AXLES INCLUDES: 1 x PE1555 BEARING 1-1/4" (14125A) 1 x PE1600 BEARING 1-3/4" (25580) 1 x PE1855 RACE 1-1/4" 8-LUG (14276) 1 x PE1900 RACE 1-3/4" (25520) 1 x PE2101 UFP SEAL 1-3/4" (21333) 1 x PH2012 x COTTER PIN 1/8" x 1-1/4" (UFP AXLE)

PG2032

DISC BRAKE ROTOR KIT 10" 5L [NO CAL] EA. - UFP

PG2070-L ~ DISC BRAKE ASSEMBLY 5-LUG GREASED (DEXTER / UFP)

To Add brakes to a trailer that was never equipped with them, Confirm there is At least four-inches of clearance from the brake mounting plate on the axle or torsion arm to the outside edge of the frame. Magic Tilt Brake Assembly ~ PG2070-L Good to know: - Bearings, Races and seals are installed in rotors and greased (Ready-To-Go). - 2 x PE2050 Replacement Seals are in the box (Loose) To accomodate non-UFP spindles if needed. Customer is responsible for determination. - Ships with PG4856 Double banjo fittings to connect brake lines. - Includes UFP hub mounting hardware. If using on non-UFP axles with 1" Spindle Threads you'll also need the PH2160 Conversion Kit (Not Included). Included in this kit: 10 x PD2250 Lug Nut 13/16" 2 x PE1400 Bearing 1-1/16" (44649) - Installed 2 x PE1450 Bearing 1-3/8" (68149) - Installed 2 x PE2055 Seal 2.57" x 1.68" UFP (257-168) - Installed 2 x PF1054 Bearing Protector SS 1.980 2 x PF1060 Bearing Protector Bra 1.980 2 x PG2026-1 Disc Rotor And Hub 10" 5-Lug Plated UFP 1 x PG5003 Disc brake caliper assembly LH UFP db3 (Double Banjo Fitting) 1 x PG5005 Disc brake caliper assembly RH UFP db3 (Double Banjo Fitting) 4 x PG5007 Disc Caliper Bolt 7/16" x 1" Shcs (UFP) 2 x PH2012 Cotter Pin 1/8" x 1-1/4" Plated UFP 1 x PG4862 Caliper Fitting Plug Brass 2 x PH1980 Spindle Nut 13/16" UFP 2 x PH2108 Spindle Nut Retainer UFP 2 x PH2065 Axle D-Washer 3/4" x 3/32" UFP 2 x PE2050 Seal 2.55" x 1.71" Non-UFP - Loose Owners Manual

PG2071-L ~ DISC BRAKE ASSEMBLY 6-LUG GREASED (DEXTER / UFP)

REPRESENTATION PHOTO IF YOU WANT TO ADD BRAKES TO A TRAILER THAT WAS NEVER EQUIPPED WITH THEM, MAKE SURE THERE IS AT LEAST FOUR-INCHES OF CLEARANCE FROM THE BRAKE MOUNTING PLATE ON THE AXLE OR TORSION ARM TO THE OUTSIDE EDGE OF THE FRAME. MAGIC TILT DISC BRAKE ASSEMBLY ~ PG2071-L - BEARINGS, RACES AND SEALS ARE INSTALLED IN ROTORS AND GREASED (READY-TO-GO). - 2 x PE2100 REPLACEMENT SEALS ARE INCLUDED (LOOSE) TO ACCOMODATE NON-UFP SPINDLES IF NEEDED. CUSTOMER IS RESPONSIBLE FOR DETERMINATION. - COMES WITH PG4856 DOUBLE BANJO FITTING TO CONNECT BRAKE LINES. - INCLUDES UFP HUB MOUNTING HARDWARE. IF USING ON NON-UFP AXLES WITH 1" SPINDLE THREADS YOU WILL NEED THE PH2165 CONVERSION KIT (NOT INCLUDED). INCLUDES: 12 x PD2250 LUG NUT 13/16" 2 x PE1550 BEARING 1-1/4" (15123) - INSTALLED 2 x PE1600 BEARING 1-3/4" (25580) - INSTALLED 2 x PE2101 SEAL 3.37" x 2.13" UFP (21333) - INSTALLED 2 x PF1101 BEARING PROTECTOR SS 2.441" 2 x PF1063 BEARING PROTECTOR BRA 2.441" 2 x PG2027-1 DISC ROTOR AND HUB 12" 6-LUG PLATED UFP 1 x PG500 3 DISC BRAKE CALIPER ASSEMBLY LH UFP DB3 (DOUBLE BANJO FITTING) 1 x PG5005 DISC BRAKE CALIPER ASSEMBLY RH UFP DB3 (DOUBLE BANJO FITTING) 4 x PG5007 DISC CALIPER BOLT 7/16" x 1" SHCS (UFP) 2 x PH2012 COTTER PIN 1/8" x 1-1/4" PLATED UFP 1 x PG4862 CALIPER FITTING PLUG BRASS 2 x PH1980 SPINDLE NUT 13/16" UFP 2 x PH2108 SPINDLE NUT RETAINER UFP 2 x PH2066 AXLE D-WASHER 3/4" x 3/16" UFP 2 x PE2100 SEAL 3.37" x 2.23" NON-UFP - LOOSE OWNERS MANUAL

PG5034 ~ DISC BRAKE CALIPER 3.5

6K (DEEMAXX CALP-3-6K-MAXX)

REPRESENTATION PHOTO MAGIC TILT DISC BRAKE CALIPER ~ PG5034 APPLICATION: 3.5K 10" 5-LUG AND 6K 12" 6-LUG DEEMAXX BRAKING SYSTEMS WITH SLIP-OVER ROTORS OR ONE-PIECE HUB/ROTORS WITH CORRECT MOUNT PLATE (NOT INCLUDED) INCLUDES BRAKE PADS NOT COMPATIBLE OTHER BRAKE BRANDS

PG5058 ~ DISC BRAKE ADAPTER PLATE (DEXTER / UFP)

REPRESENTATION PHOTO MAGIC TILT ADAPTER PLATE ~ PG5058 ADAPTS 5-HOLE ROUND BRAKE PLATES TO 4-HOLE SQUARE ON 5.2K TO 7K AXLES. ALOWS DIRECT MOUNTING OF DEXTER / UFP CALIPERS ON 12" ROTORS. REQUIRES THE FOLLOWING HARDWARE (NOT INCLUDED) 5 X PY0215 3/8" x 1-1/14" BOLT 5 X PY1305 3/8" NYLOCK NUT

PH2160 ~ CONVERSION KIT (5-LUG 3.5K UFP ROTORS & HUBS to NON-UFP AXLES)

REPRESENTATION PHOTO MAGIC TILT HUB/ROTOR CONVERSION KIT ~ PH2160 INCLUDES: ENOUGH HARDWARE TO CONVERT TWO 5-LUG ROTORS OR HUBS TO EITHER 1" D OR 1" ROUND SPINDLES 2 x PE2050 SEAL 1-3/8" NON-UFP (171-255) 2 x PH2014 COTTER PIN 1/8" x 1-3/4" (1" SPINDLE THREADS) 2 x PH2000 AXLE NUT 1" CASTLE NON-UFP 2 x PH2105 TANG WASHER (1" D-SPINDLES) 2 x PH2070 SPINDLE WASHER (1" D-SPINDLES) 2 x PH2060 SPINDLE WASHER (1" ROUND SPINDLES)

PH2165 ~ CONVERSION KIT (6 & 8-LUG UFP ROTORS & HUBS TO NON-UFP AXLES)

REPRESENTATION PHOTO MAGIC TILT HUB/ROTOR CONVERSION KIT ~ PH2165 INCLUDES: ENOUGH HARDWARE TO CONVERT TWO 6 OR 8-LUG ROTORS OR HUBS TO EITHER 1" D OR 1" ROUND SPINDLES 2 x PE2100 SEAL 1-3/4" NON-UFP (22333) 2 x PH2014 COTTER PIN 1/8" x 1-3/4" (1" SPINDLE THREADS) 2 x PH2000 AXLE NUT 1" CASTLE NON-UFP 2 x PH2105 TANG WASHER (1" D-SPINDLES) 2 x PH2070 SPINDLE WASHER (1" D-SPINDLES) 2 x PH2060 SPINDLE WASHER (1" ROUND SPINDLES)
